4K AI Turret Dome Security Camera

Showcase your message here
$289.00
$289.00
4K AI Turret Dome Security Camera image 0
4K AI Turret Dome Security Camera image 1
4K AI Turret Dome Security Camera image 2

Product details

INFO BLOCK TITLE

ESP 4K Pro Series Smart AI Turret Dome Camera Active Deterrence 30FPS ESP-PTD828-2A-FCDN

Smart AI Features:
1. Face Detection (Facial Analysis) 2. Pedestrian Detection & Vehicle Detection 3. Perimeter Intrusion Detection 4. Line Crossing Detection 5. Cross Counting 6. Stationary Object Detection 7. Heatmap 8. Crowd Density Detection 9. Queue Length Detection 10. License Plate Detection 11. Rare Sound Detection

Imaging Device 1/2.8" Effective Pixels 8MP 3840(H)x2160(V) Min. Illumination Color 0.007lux @ F1.0(AGC ON) ; B/W 0 lux @ IR ON Focal Length (Zoom Ratio) 2.8 Max. Aperture Ratio F No. 1.2 IR LED 2 Warm Light 2 IR Viewable Length Up to 30m Warm Light Viewable Length Up to 25m Image Setting Full Color Mode/Day & Night Mode/Schedule Wide Dynamic Range WDR Operating Conditions -30～+55°C/less than ≤ 95% RH Ingress Protection IP67 Input Voltage / Current D12V/POE(IEEE802.3af) Color / Material White/Metal

Imaging Device 1/2.8"
Effective Pixels 8MP 3840(H)×2160(V)
Min. Illumination Color 0.007lux @ F1.6(AGC ON); B/W 0 lux @ IR ON
Focal Length (Zoom Ratio)/Max. Aperture Ratio 2.8 mm/F No. 1.6
Angular Field of View Horizontal: 92°, Vertical: 46°, Diagonal: 110° Horizontal: 88°, Vertical: 44°, Diagonal: 105°
Min. Object Distance 2m
Lens Type Fixed(M12/F1.6)
IR LED 1
Warm Light 2
IR Viewable Length/Warm Light Viewable Length Up to 20_25m/Up to20m
Wide Dynamic Range WDR
Image Setting Full Color Mode/Day & Night Mode/Smart Illumination
White Balance Auto/Manual
Electronic Shutter Speed 1/5 ~ 1/20000s
On-Board Storage Micro SD slot, up to 1TB
Audio Built-in microphone & Speaker
Hardware Reset Yes
Smart Feature Face Recognition, Pedestrian & Vehicle, Perimeter Intrusion, Line Crossing, Object Detection, Crossing Counting, Heat Map, Crowd Density, Queue Length, License Plate, Rare Sound, Intrusion, Region Entrance, Region Exiting
Ethernet RJ45(10/100BASE-T)
Video Compression Format H.265/H.264
Max. Resolution 8MP 3840(H)×2160(V)@30fps
Video Quality Adjustment 256Kbps ~ 16Mbps
Protocol TCP/IP,HTTP,DHCP,DNS,DDNS,RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP
Application Programming Interface ONVIF( Profile S/G/T)
Operating Conditions -35～+60°C/less than ≤ 95% RH
Ingress Protection IP67
Input Voltage / Current DC12V: max 5.6W; POE(48V): max 7.2W
Mechanical Metal
