8 Channel 12MP H.265+ Smart POE NVR With 44TB (2x22TB) HDD Capacity - HDD Not Included

The ESP 8-Channel 12MP H.265+ Smart PoE NVR is a powerful network video recorder designed to handle high-resolution surveillance footage. With its ability to record up to 8 channels of 12MP video, this NVR is ideal for large-scale security applications. The advanced H.265+ compression technology ensures efficient storage and minimal bandwidth usage. The NVR can handle 44TB of storage capacity (22TBx2 HDD not included) for ample video retention. Its PoE (Power over Ethernet) functionality simplifies installation by providing power and data transmission through a single Ethernet cable. Includes Free P2P, mobile app and VMS. Video Resolution 12MP/8MP/5MP/4MP/3MP/1080p/720p Video Recording Bandwidth Inputs 320M Video Recording Bandwidth out 320M Frame rate 12MP:30fps 4K:120fps 4MP:240fps 2MP:480fps AI Face Detection / Pedestrian Detection / Vehicle Detection / Cross Counting / Heat Map / Crowd Density Detection / Perimeter Intrusion Detection / Line Crossing Detection / Queue Length Detection / License Plate Detection / Rare Sound Detection Playback Max 8CH playback Alarm Input/out 8 in /1 out PoE 8*RJ45, 100 Base-T 802.3at/af HDD  2 SATA HDD, up to 12TB Operating Temperature/Humidity Temperature: -10°C~+50°C (14°F ~ 122°F) Humidity: Less than 90%RH

Model Name		ESP-XVR1616
Video	Resolution	12MP/8MP/5MP/4MP/3MP/1080p/720p
Recording Bandwidth	Inputs	320M
	out	320M
Performance
Live/Playback	Compression	Audio: G.711a Video: H.264/H.265/H.264+/H.265+
	Frame rate	12MP:30fps 4K:120fps 4MP:240fps 2MP:480fps
	AI	yes
	Event	MD (Sensitivity Level 1~8)
		Video Loss
		Beep, Email, Push notification to Mobile APP
	Playback function	Fast forward / backward (2x, 4x, 8x,16x)
		Slow forward (1/2x, 1/4x, 1/8x,1/16x)
	Playback	Max 8CH playback
Interface
P/W Reset		Factory Reset: Press 10 seconds
Monitors	VGA	1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ）
	HDMI	1（1024*768,1280*720,1280*1024,1440*900, 1920*1080,2560*1440(2K),3840*2160(4K) ）
Connections	PoE	8*RJ45, 100 Base-T 802.3at/af
	Ethernet	2 RJ45 100/1000 Base-T
	USB	USB2.0*1(front) USB3.0*1+USB2.0*1(rear)
	Audio out	1 in / 1 out
	E-Sata	1
	HDD	2 SATA HDD / Up to 22TB ea.
	Line in	1
	RS485	1
	Alarm Input/out	8 in / 1 out
General
OSD Language		English/French/Spanish/Portuguese/German/Italian/Greek/ Danish/Finnish/Russia/Hebrew/Turkish/Bulgarian/Arabic/Korean/ Japanese/Thai/Hindi/Romanian/Dutch/Polish
Mechanical design	Dimension (WxDxH)	378*317*53mm
Electrical	Input Voltage/Current	48V/2A
	Power consumption (excluding hard disk)	6W
Environmental	Operating Temperature/Humidity	Temperature: -10°C~+50°C (14°F ~ 122°F) Humidity: Less than 90%RH
