| Video |
Resolution |
12MP, 8MP,5MP, 3MP ,2MP (1080P),1.3MP (960P),1.0MP (720P) |
| Recording Bandwidth |
Inputs |
|
128M |
|
| out |
|
128M |
|
| Performance |
| Live/Playback |
Compression |
Audio: G.711a; Video: H.264/H.265 |
| Frame rate |
4K:45fps;4MP:90fps;2MP:180fps |
| AI |
yes |
| Event |
MD (Sensitivity Level 1~8) |
| Vide loss |
| Beep, Email,
Push notification to Mobile APP |
| Playback function |
Fast forward / backward (2x, 4x, 8x,16x) |
| Slow forward (1/2x, 1/4x, 1/8x,1/16x) |
| Playback |
Max 4CH playback |
Max 8CH playback |
Max 16CH playback |
|
fisheye |
Use WEB CMS, device does not support |
| Interface |
| P/W Reset |
|
Factory Reset: Press 10 seconds |
| Monitors |
VGA |
1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ） |
| HDM |
1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080, 2560*1440, 3840*2160/EDID） |
| Connections |
PoE |
N/A |
| Ethernet |
1 RJ45 100/1000 Base-T |
| USB |
USB2.0*1(front); USB2.0*1+(rear) |
| Audio out |
1 |
| E-Sata |
1 optional, not supported by default |
| HDD |
1 SATA HDD, up to 22TB (Design reserved 2HDD or 1HDD+1ESATA) |
| Line in |
1 optional, not supported by default |
1 optional, not supported by default |
1 |
| RS485 |
1 optional, not supported by default |
| Alarm Input/out |
4 in /1 out optional, not supported by default |
8 in /1 out optional, not supported by default |
| General |
| Mechanical design |
Dimension (WxDxH) |
300X227X53mm |
| Electrical |
Input Voltage/Current |
DC12V/2A |
| Power consumption (excluding hard disk) |
3W |
3W |
3W |
| Environmental |
Operating Temperature/Humidity |
Temperature: -10°C~+50°C (14°F ~ 122°F)
Humidity: Less than 90%RH |
