8CH 8PoE Smart NVR
- Regular price
- $489.00
- Sale price
- $489.00
- Regular price
Product details
INFO BLOCK TITLE
- Maximum support for 8 channels of 4K IP camera input, 8 PoE channels
- H.265 encoding and decoding
- Supports standard ONVIF protocol
- With Gigabit Ethernet ports
- With 2 internal HDD drive bays, and 1 external e-SATA port
- 8 alarm inputs and 1 alarm outputs
- Supports intelligent analytics such as facial recognition, human detection, vehicle detection, license plate recognition, perimeter intrusion, and line crossing statistics
- Allows remote access from mobile devices and computers
- Supports external alarm devices and features RCA interface for voice intercom
| Model Name | ESP-XVR808 | |
| Video | Resolution | 12MP/8MP/5MP/4MP/3MP/1080p/720p |
| Recording Bandwidth | Inputs | 320M |
| out | 320M | |
| Performance | ||
| Live/Playback | Compression | Audio: G.711a Video: H.264/H.265/H.264+/H.265+ |
| Frame rate | 12MP:30fps 4K:120fps 4MP:240fps 2MP:480fps |
|
| AI | yes | |
| Event | MD (Sensitivity Level 1~8) | |
| Video Loss | ||
| Beep, Email, Push notification to Mobile APP |
||
| Playback function | Fast forward / backward (2x, 4x, 8x,16x) | |
| Slow forward (1/2x, 1/4x, 1/8x,1/16x) | ||
| Playback | Max 8CH playback | |
| Interface | ||
| P/W Reset | Factory Reset: Press 10 seconds | |
| Monitors | VGA | 1（1024*768, 1280*720, 1280*1024, 1440*900, 1920*1080 ） |
| HDMI | 1（1024*768,1280*720,1280*1024,1440*900, 1920*1080,2560*1440(2K),3840*2160(4K) ） |
|
| Connections | PoE | 8*RJ45, 100 Base-T 802.3at/af |
| Ethernet | 2 RJ45 100/1000 Base-T | |
| USB | USB2.0*1(front) USB3.0*1+USB2.0*1(rear) |
|
| Audio out | 1 in / 1 out | |
| E-Sata | 1 | |
| HDD | 2 SATA HDD / Up to 22TB ea. | |
| Line in | 1 | |
| RS485 | 1 | |
| Alarm Input/out | 8 in / 1 out | |
| General | ||
| OSD Language | English/French/Spanish/Portuguese/German/Italian/Greek/ Danish/Finnish/Russia/Hebrew/Turkish/Bulgarian/Arabic/Korean/ Japanese/Thai/Hindi/Romanian/Dutch/Polish |
|
| Mechanical design | Dimension (WxDxH) | 378*317*53mm |
| Electrical | Input Voltage/Current | 48V/2A |
| Power consumption (excluding hard disk) | 6W | |
| Environmental | Operating Temperature/Humidity | Temperature: -10°C~+50°C (14°F ~ 122°F) Humidity: Less than 90%RH |
